FS 300 T
Description
FRASTE FS 300 T: a perfect combination of quality, technology and reliability. Designed for a multipurpose use with different drilling methods - direct or reverse fluid circulation - air drilling with DTH hammer - auger dry drilling - for Water Wells, Surface soil and mineral Exploration, Geothermal drilling, Seismic, Coring. The FS 300 T features a certified and high standard construction method and improved safety systems, to face any working condition. Many options and drilling accessories are available, including the integral all-hydraulic “Fraste” automatic drill pipes loading system, for a safe and efficient drill pipes handling. It can be mounted on truck, track or trailer.
Optional
- Piston Pump
- Air Compressor
- Main Winch
- Centrifugal Pump
- Self Priming Pump
- Triplex Piston Pump
Other optional items are available on demand for a highly customized version of the rig.
MORE INFO ABOUT
FS 300 T ?
FILL IN THE FORM!
Pull-up | 18000 daN (40465 lbf) | |
Pull-down | 13000 daN (31473 lbf) | |
Max rotary head torque | 2900 daNm (213893ft lbf) | |
RATED DRILLING CAPACITY | 400 mt (1312 ft) | |
